8-Port PS/2 VGA KVM Switch
CS9138Снет от производство
KVM превключвател с PS/2 конзола за 8 сървъра. Каскадира се до 3 нива за общо 512 компютъра; избор на порт с бутони на предния панел, горещи клавиши или OSD.
Характеристики
- One PS/2 console controls 8 computers.
- Cascadable up to 3 levels - provides up to 512 computers.
- Computer selection via front panel pushbuttons, hotkeys or On Screen Display (OSD).
- Keyboard and mouse emulation for error free booting.
- Supports Microsoft IntelliMouse, Logitech MouseMan, FirstMouse, IBM Scrollpoint Mouse.
- OSD automatically adjusts to resolution changes.
- Auto Scan function to monitor computer operation.
- Superior video quality: up to 1920 x 1440; DDC2B.
- Available in silver and black.
- Special design for easy stacking.
- Rack mountable in 19" (1U) system rack.
- Multiplatform support: Windows 2000/XP/Vista, Linux and FreeBSD.
- For more information about KVMs which can connect to CS9138, see Compatible KVM Table.
Връзки към компютри
- Директно
- 8
- Максимум
- 512 (via Cascade)
- Избор на порт
- OSD, Hotkey, Pushbutton
Конектори
- Конзолни портове
- 1 x HDB-15 Female (Blue) 1 x 6-pin Mini-DIN Female (Purple) 1 x 6-pin Mini-DIN Female (Green)
- KVM портове
- 8 x HDB-15 Male (Blue) 8 x 6-pin Mini-DIN Female (Purple) 8 x 6-pin Mini-DIN Female (Green)
- Захранване
- 1 x DC Jack (Black)
Бутони и превключватели
- Захранване
- 8 x Pushbutton
Индикатори
- Онлайн
- 8 (Green)
- Избран
- 8 (Orange)
- Захранване
- 1 (Blue)
Емулация
- Клавиатура / мишка
- PS/2
- Видео
- 1920 x 1440; DDC2B
- Интервал на сканиране
- 3, 5, 10, 15, 20, 30, 40, 60 seconds
- Консумация
- DC9V:1.5W:7BTU/h Note: ● The measurement in Watts indicates the typical power consumption of the device with no external loading. ● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
Работна среда
- Работна температура
- 0-50˚C
- Температура на съхранение
- -20-60˚C
- Влажност
- 0-80% RH, Non-condensing
Физически характеристики
- Корпус
- Metal
- Тегло
- 2.85 kg ( 6.28 lb )
- Размери (Д x Ш x В)
- 43.72 x 16.29 x 4.40 cm (17.21 x 6.41 x 1.73 in.)
- Забележка
- For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
