Превключвател за компонентно видео (YPbPr) със стерео аудио за четири устройства към един HD монитор или проектор. Превключване с бутони или IR дистанционно.
Характеристики
- Displays the video output of four digital devices on a single high definition monitor or projector.
- Stereo audio support.
- Quick and easy switching via front panel pushbuttons or IR remote control.
- Electronic switching for greater reliability and durability.
- Easy installation.
- Complete home theater switching solution.
Спецификация
- Връзки към устройства
- 4
- Избор на порт
- Push Buttons,IR Remote Control
Конектори
- Вход
- 4 x RCA Female (Green) 4 x RCA Female (Blue) 4 x RCA Female (Red) 4 x RCA Female (White)
- Аудио
- 4 x RCA Female (Red) 1 x RCA Female (White) 1 x RCA Female (Red)
- Изход
- 1 x RCA Female (Green)
- Видео
- 1 x RCA Female (Blue) 1 x RCA Female (Red)
- Захранване
- 1 x DC Jack (Black)
Бутони и превключватели
- Захранване
- 4 x Pushbutton
Индикатори
- Онлайн
- 4 (Orange)
- Избран
- 4 (Green)
- Консумация
- DC 5.3V, 0.8W (Max.) Note: ● The measurement in Watts indicates the typical power consumption of the device with no external loading. ● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
- Видео
- 1600 x 1200 @ 60Hz; 480p, 720p, 1080i, 1080p
Работна среда
- Работна температура
- 0-50˚C
- Температура на съхранение
- -20-60˚C
- Влажност
- 0 - 80% RH, Non-Condensing
Физически характеристики
- Корпус
- Metal
- Тегло
- 0.85 kg
- Размери (Д x Ш x В)
- 26.00 x 7.66 x 4.40 cm
- Забележка
- For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
