Свързва до 4 HDMI източника към един дисплей и превключва между тях при True 4K (4096x2160@60Hz 4:4:4). Поддържа HDR10+ и автоматичен избор на активния вход.
Характеристики
- Allows up to 4 HDMI sources to be connected to one HDMI display
- HDMI (3D, Deep Color, 4K); HDCP 2.2 compliant
- Superior video quality- True 4k resolutions of 4k x 2k @ 60 Hz (4:4:4)
- Supports HDR10+
- Supports IR extension
- Built-in bi-directional RS-232 serial port for high-end system control
- Auto switching modes for auto port selection
- LED indication of source device status
- Plug-and-play
Бутони и превключватели
- DIP превключвател
- Auto Switch ON/OFF
Видео вход
- Интерфейси
- 4 x HDMI Type A Female (Black)
- Импеданс
- 100 Ω
- Макс. разстояние
- 5M at 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4)
Видео изход
- Интерфейси
- 1 x HDMI Type A Female (Black)
- Импеданс
- 100 Ω
- Макс. разстояние
- 5M at 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4)
Видео
- Макс. скорост на данните
- 18 Gbps (6 Gbps Per Lane)
- Макс. пикселна честота
- 600 MHz
- Съответствие
- HDMI (3D, Deep Color, 4K) HDCP 2.2 Consumer Electronics Control (CEC)
- Макс. резолюция
- 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4)
Управление
- RS-232
- Connector：1 x DB-9 Female (Black) Baud Rate：19200 / Data Bits：8 / Stop Bits：1 / Parity：NO / Flow Control：NO
- IR
- 1 x Mini Stereo Jack Female (Black) 1 x IR Receiver
Конектори
- Захранване
- 1 x DC Jack (with locking)
- Консумация
- DC5V:0.924W:20BTU/h Note: ● The measurement in Watts indicates the typical power consumption of the device with no external loading. ● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
Работна среда
- Работна температура
- 0-40 °C
- Температура на съхранение
- -20 - 60 °C
- Влажност
- 0 - 80% RH, Non-Condensing
Физически характеристики
- Корпус
- Metal
- Тегло
- 0.47 kg ( 1.04 lb )
- Размери (Д x Ш x В)
- 20.00 x 8.21 x 2.50 cm (7.87 x 3.23 x 0.98 in.)
- Брой в кашон
- 10 pcs
- Забележка
- For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
