8-Port PS/2-USB VGA KVM Switch

Name: 8-Port PS/2-USB VGA KVM Switch
Brand: ATEN
SKU: CS1308

CS1308

Управлява 8 компютъра от една конзола (клавиатура, мишка, VGA монитор) с PS/2 или USB връзка. Каскадира се до 2 нива за контрол на общо 64 компютъра.

Характеристики

One USB-PS/2 console controls 8 computers
Cascade up to 2 levels - control up to 64 computers
Dual Interface - supports computers with PS/2 or USB keyboards and mice
Multiplatform support - Windows 2000/XP/Vista, Linux, Mac, and Sun
Video DynaSync™ - Exclusive ATEN technology eliminates boot-up display problems and optimizes resolution when switching between ports
Supports USB keyboards for PC, Mac and Sun
Auto PS/2 and USB interface detection
USB or PS/2 keyboard and mouse emulation - computers boot even when the console focus is elsewhere
Superior video quality - up to 2048 x 1536; DDC2B
Computer selection via front panel pushbuttons, hotkeys and multilingual on-screen display (OSD) menu
Two level password security - only authorized users view and control computers; up to four users and an administrator with a separate profile for each
Auto Scan feature for monitoring user-selected computers
Hot pluggable - add or remove computers without having to power down the switch
Buzzer on/off via hotkey and OSD
Firmware upgradeable
No software installation required
Designed for desktop or rack mount (19" system rack, 1U)

Клавиатура / мишка: PS/2, USB
Видео: 2048 x 1536; DDC2B
Интервал на сканиране: 1 – 255 Seconds (Default: 5 secs)
Консумация: DC5.3V:2.34W:19BTU/h Note: ● The measurement in Watts indicates the typical power consumption of the device with no external loading. ● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.

Корпус: Metal
Тегло: 1.89 kg ( 4.16 lb )
Размери (Д x Ш x В): 43.72 x 16.13 x 4.40 cm (17.21 x 6.35 x 1.73 in.)
Забележка: For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
